SDM630-MBUS-MID three phase digital multifunction meter

SDM630-100AMP-MBUS-MID single/three phase digital multifunction meter (100A Direct Connected – Pulse & M-BUS outputs)

The SDM630 is a new generation modern design power monitor that will measure and display electrical power quality parameters. It has been engineered to cover most applications (Single Phase and Three Phase networks / Built in Pulsed and M-bus / Import and Export kWh), replacing the need for several different models of this power meter.

As the demand for MID certified meters has increased, we have obtained annex B and D of the EC Directive 2004/22/EC. This power meter has been tested and certified for single or three phase networks and import and export active energy (kWh).

The SDM630 is produced to the highest quality and utilises the latest microprocessor and technology. It has a blue back-lit display and 16 different measuring parameters. With built in pulsed outputs and M-bus it is fully compatible for integration with BMS and remote monitoring systems.
